Sanitary Angle Type Strainer

Application
The manhole is mainly used for pressure vessel in the fields of Food, wine, beverage, pharmaceutical,etc.

Design and features
• Outward opening manhole cover
• Plastic hand wheel or stainless steel hand wheel
• Internal surface：Ra0.8μm-0.5μm
• Outside surface: Mirror polish, Matt finish, sand-blasting finished.
• Max. pressure：0-1bar
• Gasket：EPDM 、NBR、SILICON、
• Height：80-200
• Material：AISI304(1.4301)/316L(1.4404)
• Size: 200-700

Technical specifications
• Fixed 360 Degree Tank Spray Balls for Cleaning
• Cleaning angle: 360°
• Sphere options: 1) round ball; 2) oval ball
• Material：316L/304
• Connections：female thread/male thread ,clamp, Bolt ,welded

Sampling valve
The sampling valve is no dead angle-free design and the end face connected to the container does not has a dead zone phenomenon.
• It is mainly used for sample collection of materials in tank equipment or pipelines. It can also be installed at the lowest point of tank equipment or pipelines to drain residual liquid.
• Working principle: the handwheel rotates the valve stem clockwise together with the sealing ring. At this time, the valve is opened for sampling. The handwheel rotates the valve stem counterclockwise together with the sealing ring. The valve is closed.
• Applicable temperature: -10 ° C to 130 ° C
• valve body material: AISI 304 AISI 316L
• Sealing material: PTFE
• Connection method: clamp type, thread type, welding type, nut type

Technical specifications
• Fixed 360 Degree Tank Spray Balls for Cleaning
• Cleaning angle: 360°
• Sphere options: 1) round ball; 2) oval ball
• Material：316L/304
• Connections：female thread/male thread ,clamp, Bolt ,welded

Applicarions
Filter are widely used in the auxiliary service for food processing, cosmetic, chemicals and pharmacy industries. With high hygienic design,it is mainly used to filter the particulates which will damage pumps and some other equipments.The filter is basiclly consist of inlet outlet and filter body. Filter mesh is installed inside to remain all particles equal or greater than mesh

Technical Specifications
• Size：DN25-DN150 1″-6″
• Working temperature：-10℃-120℃(EPDM)
• Max. working pressure：10bar 145PSI
• Gasket：Silicon MVQ FPM
• Connection: clamp,thread, weld
• Standard:DIN,SMS,RJT,IDF,3A
• Hole Dia：0.5mm to 2.0mm
• Mesh size: 30 Grits to 300 Grits
