Sanitary Rotary Cleaning Ball

Applications
• Flange sight glasses is comprised of stainless steel frame and tempered glass. Through it, operator can observe the flowing of the media clearly and precisely in the fields of food, cosmetics,pharmaceutical and fine chemicals industries.

Technical specifications
• Size from 1.5″-8″-DN40-DN200
• Assemble flange with glass by using hexagon socket bolts
• Material：AISI 304(1.4301) AISI 316L(1.4404)
• Max. Temperature：-10℃-130℃
• Max. Pressure：10bar

Working Principle:
Single function (spring reset)
Compressed air from the air intake(A) to enter into the space between the cylinder and the reversing accessory piston(B), made the plunger separate and move to the bottom of cylinder,force the spring
compressed,the air of cylinder is discharge through the vent (C),make the piston(B) anti-clockwise 90 degree rotation through guide groove drive Reversing master device(D)in the meantime.(means valve
opened)
After the solenoid valve for compressed air backward,the piston(B) cylinder move to the top under the elastic spring.The air of middle air cavity is discharge through the air pipe connector by solenoid valve .At that moment the piston(B) clockmise 90 degree rotation through the guide groove drive Reversing master device(D).(means valve closeed

Technical specifications
• Fixed 360 Degree Tank Spray Balls for Cleaning
• Cleaning angle: 360°
• Sphere options: 1) round ball; 2) oval ball
• Material：316L/304
• Connections：female thread/male thread ,clamp, Bolt ,welded

Applications
Butterfly valve whatever manual or automatic operation can be used in food processing, pharmaceutical and chemical products, industrial fluid applications.

Technical Specification
Size: DN10-DN300, 1/2″-12″
Temperature: 130 ℃
Pressure: 10bar
Material: ASTM T304 / T316L, 1.4301 / 1.4404
Connection: Threaded, Flange Welding, Clamp, etc.
Operation Standard: DIN SMS RJT 3A ISO IDF
Manual operation: Muti-handles, Pull handles
Pneumatic Operation: Single acting, Double acting, Triple action

Applicarions
Filter are widely used in the auxiliary service for food processing, cosmetic, chemicals and pharmacy industries. With high hygienic design,it is mainly used to filter the particulates which will damage pumps and some other equipments.The filter is basiclly consist of inlet outlet and filter body. Filter mesh is installed inside to remain all particles equal or greater than mesh

Technical Specifications
• Size：DN25-DN150 1″-6″
• Working temperature：-10℃-120℃(EPDM)
• Max. working pressure：10bar 145PSI
• Gasket：Silicon MVQ FPM
• Connection: clamp,thread, weld
• Standard:DIN,SMS,RJT,IDF,3A
• Hole Dia：0.5mm to 2.0mm
• Mesh size: 30 Grits to 300 Grits
